Disassembled CNC Plasma Cutting Machine
| Technical Specification | ||
| Model | AT-T1530D | AT-T2060D |
| Effective cutting range(mm) | 1500×3000mm | 2000*6000mm |
| Cutting speed (mm/min) | 50-8000 | |
| Input power source | 380v±10% VAC,50/60HZ,three phase | |
| Input Machine body | 220V±10%V AC, 50/60HZ, Single phase | |
| Plasma cutting thickness(mm) | 0.5-30mm (According to your plasma power source) | |
| Plasma cutting gas | compressed air | |
| Cutting torch | one plasma cutting torch with plasma power source | |
| CNC controller system | F2100T | |
| THC | Build-in controller | |
| Motor | Leadshine Stepper motor and drive | |
| Drive type | Bilateral drive | |
| Operation precision | ±0.2mm | |
| Guide length ×guide width ×guide thickness (mm) | 3500×273×60 | |
| Nesting software | StarCam or Fastcam | |
| Gas pressure (Mpa) | 0.5 | |
